8–14 SERVICE AND MAINTENANCE
Service Interval, Specification and Capacity
BRAKE FLUID
The fluid level in the brake fluid tank should
be checked according to the “Maintenance
Schedule”.
Before checking the fluid level, clean the
area around the tank cap thoroughly. The
fluid level in the brake tank must be MAX
mark.
If the level falls below the MIN mark, add the
fluid to MAX mark. Do not overfill.
Low fluid level can indicate a leak in the
brake system. Have the system checked at
nearest Ssangyong Dealer.
Service interval
Specification
Capacity
Inspect every 15,000km
Change every 60,000km
ATF DEXRON
II, III,
ATF S-4 TOTAL FLUID ATX
Part time 1.2 ~ 1.4 L
Indirect Injection
Diesel Engine
Part time
Full time (TOD)
Direct Injection
Diesel Engine
Full time (TOD)
1.4 ~ 1.5 L
Gasoline Engine
