INSTRUMENTS AND CONTROLS 3–7
TACHOMETER
The tachometer indicates engine speed in
revolutions per minute.
Multiply 1,000 to the current number, then it
will be the current number of engine revolu-
tions.
Ideal engine idle speed
WARNING
Excessive speed can damage engine.
Do not let engine reach excessive
speed, indicated by pointer being in
red zone.
TEMPERATURE GAUGE FUEL GAUGE
The temperature gauge indicates the tem-
perature of engine coolant when the ignition
switch is in the “ON” position.
• H : hot
• C : cool
This gauge indicates the level of fuel remain-
ing in the fuel tank. This gauge operates only
when the ignition switch is in “ON” position.
When the fuel is added, the gauge slowly
changes to the new fuel level after the igni-
tion is turned on. The needle moves when
braking, accelerating or making turns. This
is caused by the movement of the fuel in the
tank.
• F : Full
• E : Empty
CAUTION
The engine can overheat.
•
If the pointer reaches the red zone,
stop the vehicle.
•
Allow engine to cool.
NOTE
Fill up fuel tank before the needle
reaches “E”.
Diesel
Gasoline
700~800 rpm
650~750 rpm
General Type
Black-Face Type(Diesel)
Black-Face Type(Gasoline)
Black-Face Type
Black-Face Type
General Type
