Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 1
1 General instructions
Contents in this chapter
General
This Workshop Manual is intended for GGP Park models 2008-2015 with steering chain or
steering wire. The GGP Park model 2015 with steering cylinder has a separate workshop
manual. The article numbers and product names are designated in the tables under
“Technical specification” at page 18.
This Manual do not cover repair instructions for the engines. Regarding engines, contact
the respective representative in the actual country.
This Manual and its specifications are valid for machines in their original design. In case of
modified or changed machine, i.e. the engine is replaced, the manual accordance is limited.
The manual is divided in the following chapters:
Chapter 1 is this chapter
Chapter 2 Chassis
Chapter 3 Steering
Chapter 4 Hydraulic system
Chapter 5 Belts
Chapter 6 Control Wires
Chapter 7 Electrical system
1.3 Unpacking and assembly......... 4
1.3.1 Unpacking.............................. 4
1.3.2 Battery .................................. 5
1.3.3 Final checks........................... 6
1.4 Service ....................................... 7
1.4.1 Service times......................... 7
1.4.2 First Service........................... 8
1.4.3 Basic service.......................... 9
1.5 Engine - Transmission ............. 14
1.5.1 Engine oil and oil filter, interval16
1.5.2 Air filter, serviceinterval.......... 17
1.5.3 Transmissions........................ 17
1.6 Technical specifications .......... 18
1.6.1 Machines ............................... 18
1.6.2 General tightening torque ...... 31
1.7 Instructions for use .................. 31
1.1 Introduction................................2
1.1.1 Responsibility declaration.......2
1.1.2 How this manual is used ........2
1.1.3 Abbreviations..........................2
1.2 Safety Precautions ....................2
1.2.1 Symbols and warnings ...........3
1.2.2 Warm parts.............................3
1.2.3 Moving parts...........................3
1.2.4 Lifting and blocking up............3
1.2.5 Cleanliness.............................3
1.2.6 Tightening torque ...................3
1.2.7 Sharp edges...........................3
1.2.8 Replacement parts .................3
1.2.9 Inspection...............................3
