2014-09-20 Workshop Manual, GGP Park 4 Hydraulic system 19
4.7 Trouble shooting
Warning!
Hydraulic oil under pressure can be
very dangerous if hoses, lines or oth-
er distribution parts are leaking. To
avoid personal injuríes, always wear
protection gloves and protection
goggles during works with the hy-
draulic system.
4.7.1 Drive system
Before the trouble shooting takes place, it is
provided that the following states are fulfilled:
• Machines with external pump; the axle by-
pass valves are in drive position. See the fig-
ure..
• The clutch release lever (levers) shall be in
the drive position. See the figures.
• Oil level in the oil container as desired.
• No air in the hydraulic oil.
4 WD machines, internal pump
Clutch release lever, 4WD, int. pump
Clutch release lever, 4WD, ext. pump
Clutch release lever, 2WD
