Edition Manual Chapter Page
2014-09-20 Workshop Manual, GGP Park 4 Hydraulic system 2
4.1 Safety
Hydraulic oil under pressure can be very dangerous if hoses, lines or other
distribution parts are leaking. To avoid personal injuríes, always wear protection
gloves and protection goggles during works with the hydraulic system.
Before starting the motor, place the machine outdoors or install an extraction device
for the exhaust fumes. Otherwise the personel will be poisoned.
Cleanliness is mandatory at all works with the hydraulic system. Foreign substances
and contaminations will jeopardize the function and reliability of the system. Always
protect and close openings of hoses, lines and connections when replacing compo-
nents.
4.2 Configuration
The machines are equipped with systems according to the table below:
Art.
Number
Machine
2 Wheel drive
4 Wheel drive
Hydraulic pump
in the rear axle drive
See "4.3" at page 5
Separate hydraulic
pump
See "4.4" at page 8
Hydraulic steering, 4WD
See "" at page 11
Hydraulic steering, 2WD
See "4.6" at page 18
Hydraulic implement
lifter
See "" at page 11
13-6002-XX Mountfield 4140H X X
13-6003-XX Mountfield 4155H X X
13-6004-XX Mountfield 4155H 4WD X X
13-6100-XX Park Silent X X
13-6101-19 Park Compact 13 Manual gear 5-speed
13-6102-XX Park Compact 14
Castelgarden XK 140 HD
Béal Master MBF 13,5
Mountfield 4135H
XX
13-6103-XX Park Compact 16
Castelgarden XK 160 HD
Béal Master MBF 15,5
Mountfield 4155H
XX
13-6104-XX Park Compact 16 4WD
Castelgarden XK4 160 HD
Béal Master MBF 15,5
Mountfield 4155H 4WD
XX
13-6105-99 Mountfield XK 13 Manual gear 5-speed
13-6106-99 Mountfield XK 16 X X
13-6107-99 Mountfield XK 16 4WD X X
13-6109-XX Park Compact 14 X X
