13 Special Servicing Tools and Aids
13.1 Special Servicing Tools
No. Part Name Part No. Application
1 Locking strip 0000 893 5903 Blocking the crankshaft
2 Press sleeve 1118 893 2401 Installing oil seal (clutch side)
3 Press sleeve 1121 893 2400 Installing oil seal (ignition side)
4 Puller 5910 890 4400 Removing oil seals
5 - Jaws (No. 3.1 + 4) 0000 893 3706 (for clutch side only)
6 Assembly sleeve 1118 893 4602 Oil seal (clutch side)
7 Puller 1110 890 4500 Removing flywheel
8 Crimping tool 5910 890 8210 Attaching connectors to electric wires
9 Assembly drift 1110 893 4700 Fitting the piston pin
10 Clamping strap 0000 893 2600 Compressing piston rings
11 Wooden assembly block 1108 893 4800 Fitting piston
12 Carburetor and crankcase
tester
1106 850 2905 Testing crankcase and carburetor
for leaks
13 Vacuum pump 0000 850 3501 Testing crankcase for leaks
14 - Nipple 0000 855 9200
15 - Hose 1110 141 8600
16 Sealing plate 0000 855 8106 Sealing exhaust port for leakage test
17 Flange for leakage test 1128 850 4200 Leakage test
18 Setting gauge 1111 890 6400 Setting air gap between ignition module
and flywheel
19 Socket, 13 mm 5910 893 5608 Crankshaft nut
20 Socket, 19 mm 5910 893 5612
21 Torque wrench 5910 890 0301
22 Torque wrench 5910 890 0311
23 Screwdriver bit T27x125 0812 542 2104 IS (spline socket head) screws
24 Assembly hook 5910 893 8800 Removing pickup bodies
25 Installing tool 5910 890 2210 Fitting hookless snap rings in piston
26 Press arbor 1120 893 7200 Removing crankshaft bearing at
ignition side
27 Press arbor 1118 893 7200 Installing crankshaft bearings
28 Assembly hook 5910 890 2800 Detaching springs from clutch shoes
29 Installing tool 0000 890 2201 Flaring rope guide bush
30 Assembly tube 1117 890 0900 Attaching the brake spring
31 Centering tool 1118 893 3500 Centering the heating generator
32 Service tool AS (set) 5610 007 2205 Removing the crankshaft (clutch side)
33 Service tool ZS (set) 5910 007 2200 Removing the crankshaft (ignition side)
34 T-handle screwdriver
QI-5x150
5910 890 2400 For all IS screws
35 Stud puller MS 5910 893 0501 Removing bar mounting studs
36 Puller 1107 890 4500 Removing generator centering tool
37 Ohmmeter
38 Thrust piece (sleeve) 1107 894 1000 Protecting crankshaft thread
