64 MS 270, MS 280
 Inspect fan housing gasket (1)
and replace if necessary.
– Fit the fan housing and tighten
down the screws firmly
– see 3.5.
VA
146RA189
1
 Before fitting the screw (1) above
the spring, insert a 5 mm
diameter drift or punch in the hole
(arrow) to prevent the bearing
plug, with spring, slipping out of
the tank housing.
Reassemble all other parts in the
VA
146RA116
1
reverse sequence.
– Remove the carburetor
– see 12.2.1.
 Remove the short circuit wire (1)
from the switch shaft (2).
VA
146RA089
2
1
 Pry the switch shaft (1) out of the
tank housing (2).
 Carefully pull the switch shaft (1)
out of the pivot mount (3).
VA
146RA183
1
2 3
Install in the reverse sequence.
10 Master Control/
Handle System
10.1 Switch Shaft
