65MS 270, MS 280
– Remove the carburetor box cover
– see 6.4.
 Push the two retainers (arrows)
on the underside of the hand
guard apart and remove the
handle molding upwards.
VA
146RA117
– Move the switch shaft to the
normal operating position.
 Pull out the interlock lever (1).
VA
146RA118
1
 Pull the throttle rod out of the
throttle trigger sideways.
VA
146RA119
 Drive out the pin (3) with a 5 mm
drift.
 Take out the throttle trigger (2)
with torsion spring (1).
Install in the reverse sequence.
VA
146RA120
123
The torsion spring must be installed
so that it is under the interlock lever
and locates in its seat.
VA
176RA216
 Press down the interlock
lever (1).
 Press the throttle trigger (2) up
and the switch shaft (3) to
"Choke" position.
VA
146RA121
3 2
1
10.2 Throttle Trigger/Interlock Lever
10.2.1 Machines without QuickStop Super
