7-10 SERVICING INFORMATION
WIRE, CABLE AND HOSE ROUTING
WIRE ROUTING
Throttle cable
Front brake cable
Clutch cable
Engine stop switch lead wire
Clamp
CDI unit
Clamp
Clamp
Clamp
Clamp
Throttle cable
Engine stop switch lead wire
Clutch cable
Face the clamp end down.
Gnerator lead wire
