Suzuki DR 125 - Crankshaft and Conrod

3-34 ENGINE
CRANKSHAFT AND CONROD
CONROD SMALL END I.D.
Measure the conrod small end inside diameter using the dial cal-
ipers. If the conrod small end inside diameter exceeds the ser-
vice limit, replace the conrod.
$ Conrod small end I.D.
Service Limit: 14.040 mm (0.5528 in)
& 09900-20605: Dial calipers
1 Crankshaft, RH
2 Conrod
3 Bearing
4 Crank pin
5 Crankshaft, LH
