ENGINE 3-5
• Remove the rear engine mounting nut and bolt.
• Remove the front engine mounting bolts and bracket.
• Remove the upper engine mounting bolts and bracket.
NOTE:
When removing the upper mounting bolts and nuts, support the
engine with a jack.
• Remove the swingarm pivot nut and washer.
• Partially remove the swingarm pivot shaft so that the engine
can be removed.
NOTE:
Be careful not to draw out the pivot shaft.
• Gradually lower the engine.

Suzuki DR 125 Specifications

General

Displacement	124cc
Compression Ratio	9.5:1
Transmission	5-speed constant mesh
Bore x Stroke	57.0 mm x 48.8 mm
Ignition	CDI
Front Suspension	Telescopic, oil damped
Rear Suspension	coil spring, oil damped
Front Brake	Disc brake
Rear Brake	Drum
Ground Clearance	265 mm
