CAUTION
!
Be sure to replace old gasket used for bolt “A”
with new one.
Tightening torque for
bolt “A”
2–4 N–m
0.2–0.4 kg–m
1.5–2.5 lb–ft.
10) Run engine, with radiator cap removed, until radiator
upper hose is hot.
11) With engine idling, add coolant to radiator until level
reaches the bottom of filler neck. Install radiator cap,
making sure that its ear lines up with reservoir tank hose.

Suzuki F6A Specifications

General

Displacement	657 cc
Cooling System	Water-cooled
Bore x Stroke	65.0 mm x 66.0 mm
Compression Ratio	8.5:1
Fuel System	Carburetor or Fuel Injection
Maximum Torque	57 Nm (42 lb-ft) at 4, 000 rpm
Valvetrain	SOHC
Engine Type	Inline 3-cylinder
