186
REVERSE
The rear carrier is fixed, and the sun gear rotates turns in a forward direciton, so the rear internal gear turns in a reverse
direction. Thus the output shaft rotation is reversed, and the vehicle moves backward.
Operating brake, clutch
Direct clutch: connects
input shaft and sun gear
1st reverse brake: fixes
rear gear
Front Rear Input: front internal gear
Output: front carrier
Input rpm N
s
Output rpm n
i
N
s
> n
i
0 > n
I
Internal
gear
Rvse (N
i
rpm) Rvse (n
i
rpm)
Carrier Rvse (N
i
rpm) Fixed
Sun gear Fwd (N
s
rpm)
DIRECT CLUTCH
INPUT SHAFT
FRONT INTERNAL GEAR
REAR INTERNAL GEAR
OUTPUT SHAFT
SECOND BRAKE

Suzuki F6A Specifications

General

Displacement	657 cc
Cooling System	Water-cooled
Bore x Stroke	65.0 mm x 66.0 mm
Compression Ratio	8.5:1
Fuel System	Carburetor or Fuel Injection
Maximum Torque	57 Nm (42 lb-ft) at 4, 000 rpm
Valvetrain	SOHC
Engine Type	Inline 3-cylinder
