3-26

OPERATING YOUR VEHICLE

78KS0-37E

The basic operation for transfer switch

N: Neutral

4H: 4-wheel drive high range mode

4H LOCK: 4-wheel drive high range center differential lock mode

4L LOCK: 4-wheel drive low range center differential lock mode

Current Position Current Indicator Target Position Target Indicator

N4H–

4H –

4H LOCK

4H –

4L LOCK

4L LOCK 4H LOCK
