7-16
INSPECTION AND MAINTENANCE
78KS0-37E
Spark Plugs
78K056
NOTE:
For 3.2L engine, to approach the spark
plugs, you need to remove the bolts shown
in the illustration.
For nickel spark plugs (traditional type):
You should inspect spark plugs periodically
for carbon deposits. When carbon accu-
mulates on a spark plug, a strong spark
may not be produced. Remove carbon
deposits with a wire or pin and adjust the
spark plug gap.
Type A
65D434
For Type A, to access the spark plugs:
1) Remove the ignition coil cover.
2) Disconnect the coupler (1) while push-
ing the release lever.
3) Remove the bolt.
4) Pull the ignition coil out.
Type B
65D435
For Type B, to access the spark plugs:
1) Disconnect the coupler (2) while push-
ing the release lever.
2) Remove the bolts.
3) Pull the spark plug boots out.
NOTE:
When installation, make sure the wires,
couplers, sealing rubber of top cover and
washers, are correctly returned in place.
EXAMPLE
Engine Coolant: 1, 2
