5-11

OTHER CONTROLS AND EQUIPMENT

78KS0-37E

Basic Operations

78K094

(1)

(5)

(2)

(3)

(4)

(1) (2)

(3)

(4)

(6)

(7)

(6)

(7)

Type 1 AM/FM CD PLAYER WITH CD CHANGER CONTROL

Type 2 AM/FM 6-CD PLAYER WITH CD CHANGER CONTROL

Display

79K086

(1) Power on/off knob

Volume control knob

(2) Tone/balance/fader control knob

(3) Preset button 5

(4) Preset button 6

(5) Mute button

(6) Clock button H

(7) Clock button M

(A) Clock display
