7-7

INSPECTION AND MAINTENANCE

78KS0-37E

Drive Belt

(For Gasoline Engine Model)

Check the accessory drive belt only for

damage. You do not need check it for ten-

sion as it has an automatic tensioner.

If you need to replace or adjust the belt

have it done by your SUZUKI dealer.

(For Diesel Engine Model)

The drive belt tension is adjusted automat-

ically.

WARNING

When the engine is running, keep

hands, hair, clothing, tools, etc. away

from the moving fan and drive belts.

78K091

ADB

ADB: Accessory drive belt

GE: Generator

PS: Power steering pump

AC: Air conditioner compressor

L4 2.0 L V6 3.2 L

Drive Belt: 1, 2

Service Station Guide7
