2-44

BEFORE DRIVING

78KS0-37E

Instrument Cluster

1. Speedometer

2. Tachometer

3. Fuel gauge

4. Temperature gauge

5. Information display

6. MODE/ILL knob

7. TRIP knob

8. Warning and indicator lights

78K090

EXAMPLE

1 32

58867 4

Service Station Guide7
