2-54
BEFORE DRIVING
78KS0-37E
Speedometer
78K038
The speedometer indicates vehicle speed
in km/h and/or mph.
Tachometer (if equipped)
78K039
The tachometer indicates engine speed in
revolutions per minute.
Fuel Gauge
64J052
This gauge gives an approximate indica-
tion of the amount of fuel in the fuel tank.
“F” stands for full and “E” stands for empty.
If the indicator gets off the graduation of
“E” (not character “E”), refill the tank as
soon as possible.
NOTE:
The indicator moves a little depending on
road conditions (for example, slope or
curve) and driving conditions because of
fuel moving in the tank.
If the low fuel warning light (1) comes on,
fill the fuel tank immediately.
EXAMPLE
CAUTION
Never drive with the engine speed
indicator in the red zone or severe
engine damage can result.
EXAMPLE
(1)
(2)
To Next Page
