3-52 ENGINE
GEARSHIFT FORK THICKNESS
• Measure the gearshift fork thickness using the vernier cali-
pers.
 Shift fork thickness:
Standard: 4.8 – 4.9 mm
 09900-20102: Vernier calipers
GEARSHIFT CAM BEARING AND GEARSHIFT SHAFT
BEARING
Inspection
• Inspect the gearshift cam bearing for abnormal noise and
smooth rotation.
• Replace the bearings if there is anything unusual.
• Inspect the gearshift cam bearing 1, gearshift shaft bearings
2 and 3 for abnormal noise and smooth rotation while they
are in the crankcase.
• Replace the bearing if there is anything unusual.
Removal
• Remove the gearshift shaft bearing with the special tools.
 09921-20210: Bearing remover
09930-30104: Sliding shaft
• Remove the gearshift cam bearing with the special tools.
 09923-74511: Bearing remover
09930-30104: Sliding shaft

Be careful not to lean the bearing remover.

Suzuki GSR600 Specifications

General

Engine Type	4-stroke, 4-cylinder, liquid-cooled, DOHC
Displacement	599 cc
Compression Ratio	12.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Lubrication	Wet sump
Starter	Electric
Transmission	6-speed, constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	180/55ZR17M/C (73W), tubeless
Bore x Stroke	67.0 mm x 42.5 mm
Overall Length	2, 090 mm
Overall Width	795 mm
Wheelbase	1440 mm
Ground Clearance	130 mm
Seat Height	785 mm
Fuel Tank Capacity	16.5 L
