4-14 FI SYSTEM DIAGNOSIS
FI SYSTEM WIRING DIAGRAM
HO2 sensor
10 A 15 A
15 A
30 A
10 A
Speedometer
B/Y
G/R
R/Bl
Gr/W
Gr/B Gr/Y
Gr/R
Y/R
Y/B
O/G
W/Bl
# 1 # 2 # 3 # 4
# 1 # 2 # 3 # 4
Y
G
W/G
P
Y/G
B/Y
B/W B/W B/W B/W W/B
G
P/W
B/Lg
B
G/W
G/Bl
P/B
Y/W
G/B G/B
B
G/Y
B/Bl
B/Br
R
Br
Camshaft position sensor (CMPS)
Crankshaft position sensor (CKPS)
Throttle position sensor (TPS)
Intake air pressure sensor (IAPS)
Atomospheric pressure sensor (APS)
Engine coolant temperature sensor (ECTS)
Intake air temperature sensor (IATS)
Tip-over sensor (TOS)
Secondary throttle valve actuator (STVA)
Clutch lever position switch
Starter motor
Cooling fan motor
Starter relay
Side-stand switch
Side-stand relay
Fan relay
Engine stop switch
Fuel pump relay
Fuel pump
Fuel injector (FI)
Ignition coil (IG COIL)
Ignition switch
To immobilizer
Neutral indicator light
Starter switch
Gear position switch
PAIR solenoid
N
61
5
42
3
ECM
Secondary throttle position sensor (STPS)
C
E F d c b a W ] G g f e t p M ^ s X q r s 2 I 1 H
T D U 8 A J 9 P 0 9 L S G B \
O/W
W
W/G

Suzuki GSR600 Specifications

General

Engine Type	4-stroke, 4-cylinder, liquid-cooled, DOHC
Displacement	599 cc
Compression Ratio	12.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Lubrication	Wet sump
Starter	Electric
Transmission	6-speed, constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	180/55ZR17M/C (73W), tubeless
Bore x Stroke	67.0 mm x 42.5 mm
Overall Length	2, 090 mm
Overall Width	795 mm
Wheelbase	1440 mm
Ground Clearance	130 mm
Seat Height	785 mm
Fuel Tank Capacity	16.5 L
