5.6.1 General Repeat
This function is to embroider one design repeatedly along the X and Y axes.
<Fig. 5.6.1-1> will appear when General Repeat is selected in <Fig. 5.6.0-1>.
① X Repeat : Sets the number of repetitions along the X axis. The range of repetition settings is from 1 to 99.
② Y Repeat : Sets the number of repetition along the Y axis. The range of repetition settings is from 1 to 99.
③ X Design Interval : It sets the distances between the starting points of the repeated design along the X axis.
The signs of move(＋/－) determines the direction of repetition.
＋ : Repeat in the right direction
－ : Repeat in the left direction
[Fig. 5.6.1-1]
[ Note ]
The range of repetition setting [(X repetition frequency)(Y repetition frequency)] shall be smaller than 99.
Move volume set at 30mm Move volume set at 30mm
(30mm)
Move Volume
(30mm)
Move Volume
Starting Point
Starting Point
