5.3.4 Serial Input
This function is to import embroidery designs from embroidery design program Wings to
the OP Box.
Use the serial cable to connect to the OP Box. Call embroidery designs from Wings after establishing the
connection. When the screen appears, press “File”on the menu and select “Export”on the file menu. When
selecting “Other”on the export menu, the Export Output window appears. If driver has not been installed, press
“Add Driver.”When the “Add Wings I/O Driver”window appears, open the Sunstar.wio file, the Sunstar-
dedicated driver. Select the driver newly added to the Design Output window and press OK. Select the desired
format and press OK.
While designs are exported from the Wings program, select “Serial”in <Fig. 5.3.0-1> and then <Fig. 5.3.4-1>
appears. Preview and Delete functions cannot be used. Select a room number by using , and
press . Then <Fig. 5.3.4-2> appears.
