7.1.0
Error Messages and Handling
7.1.1 Main Shaft Motor and Others
7.1.2 X, Y Motor-related Errors
100
Main shaft motor stop position
error
When it is stopped, the main shaft's
angle is not 100˚
Use the lever to set the main shaft's
angle at 100˚
103 No trimming system recovery
When the trimming sensor is not
recovered upon trimming.
Check and respond to the
abnormality of the trimming system.
104 Start switch error
When the power is on, the start
button is pressed.
Check whether the start button
contacts the connector.
105 Stop switch error
When the power is on, the stop
button is pressed.
Check whether the stop button
contacts the connector.
109 Pulley ratio error When the set pulley ratio is wrong
Change the driver setting after
checking the main shaft pulley ratio.
108 Air pressure error
When the air pressure is below the
standard (Sequin)
110 AC Line error
When a problem occurs on the
joint board.
Replace the joint board
102 Main shaft motor overload error
When a thread tangles the hook, when
the needle bar's control body is bad,
and when the thread becomes tangled
during trimming, the error occurs.
Check the hook of the front head,
and turn off and on the main switch.
101 Main shaft motor driver error
Main shaft motor driver develops an error.
Turn off and on the main switch.
No. Error Name Error Description Handling
107 Valve error When the valve is opened.
200 (+X) frame limit detection
The frame move system reaches
the +X limit.
Move the frame in the -X direction.
201 (-X) frame limit detection
The frame move system reaches
the -X limit.
Move the frame in the +X direction.
202 (+Y) frame limit detection
The frame move system reaches
the +Y limit.
Move the frame in the -Y direction.
203 (-Y) frame limit detection
The frame move system reaches
the -Y limit.
Move the frame in the +Y direction.
206 Wiper return error Wiper solenoid does not return. Repairs the wiper mechanism.
207 Trimmer return error Trimmer motor does not return. Repair the trimmer mechanism.
No. Error Name Error Description Handling
204 X-axis driver error
Problems occur in the X-axis driver.
Turn off and on the main switch.
205 Y-axis driver error
Problems occur in the Y-axis driver.
Turn off and on the main switch.
7
Troubleshooting
