Sym Fiddle III 50 Service Manual

1. GENERAL INFORMATION/TROUBLE DIAGNOSIS SYM
1-10
TORQUE VALUES (ENGINE)
ITEM Q'TY
THREAD DIA
(mm)
TORQUE
VALUE(Kg-m)
REMARKS
Cylinder head bolts 2 6 0.8~1.2
Cylinder head left side cover bolts 2 6 0.8~1.2
Cylinder head nuts 4 8 0.8~1.2 Apply oil to thread
Tappet adjust hole cap 2 30 1.0~2.0
Cylinder/cylinder head two-ends bolts 4 6 0.7~1.1
Tighten to crankcase
Camshaft sprocket bolt 1 8 2.0~2.4
Right crank case cover bolts 10 6 0.8~1.2
Pulse generator bolts 2 5 0.35~0.5
Valve adjustment fixing nuts 2 5 0.7~1.1 Apply oil to thread
Spark plug 1 10 1.0~1.4
Engine oil filter screen cap 1 30 1.0~2.0
Engine oil drain plug bolt 1 12 3.5~4.5
Gear oil draining plug 1 8 1.0~1.5
Gear oil filling bolt 1 8 1.0~1.5
Oil pump flat screw 2 6 0.8~1.2
Left crankcase cover bolts 10 6 0.8~1.2
Camshaft chain tensioner pivot 1 6 0.8~1.2 Hex socket bolt
Camshaft chain adjuster bolts 2 6 1.0~1.4
Cooling fan bolts 4 6 0.8~1.2
Cooling fan cover bolt 2 6 0.7~1.1
RR. brake shoe anchor fixing nut 1 8 1.5~2.0
Shroud A/B 2 6 0.8~1.2
Start clutch lock nut 1 20 9.0~10
Flywheel nut 1 10 3.5~4.5
Transmission(Gear box) bolts 7 8 2.6~3.0
Movable drive face nut 1 12 5.0~6.0
Drive pulley nut 1 10 3.5~4.5
A.C. generator flange bolt 2 6 0.8~1.2
Start motor bolts 2 6 0.8~1.2
Crankcase bolts 1 6 0.8~1.2
Air/C connect bracket bolts 2 6 0.8~1.2
Kick starter arm bolt 1 6 0.8~1.2
Carburetor nut 2 6 0.8~1.2
Exhaust pipe bolts 2 8 3.0~3.6
Exhaust pipe connecting nuts 2 6 1.0~1.4
