Sym Fiddle III 50 Service Manual

SYM 7. CYLINDER/PISTON
7-1
MECHANISM DIAGRAM ....................7-1
PRECAUTIONS IN OPERATION .......7-2
TROUBLE DIAGNOSIS......................7-2
CYLINDER REMOVAL .......................7-3
PISTON REMOVAL............................7-5
PISTON RING INSTALLATION..........7-7
PISTON INSTALLATION....................7-8
CYLINDER INSTALLATION.............. 7-8
MECHANISM DIAGRAM
0.8~1.2kgf
-
m
