Sym Fiddle III 50 Service Manual

SYM 9. FINAL DRIVING MECHANISM
9-1
MECHANISM DIAGRAM ....................9-1
OPERATIONAL PRECAUTIONS .......9-2
TROUBLE DIAGNOSIS......................9-2
DISASSEMBLY OF FINAL DRIVING
MECHANISM......................................9-3
INSPECTION OF FINAL DRIVING
MECHANISM ..................................... 9-3
BEARING REPLACEMENT ...............9-4
RE-ASSEMBLY OF FINAL DRIVING
MECHANISM .....................................9-6
MECHANISM DIAGRAM
2.6~3.0 kgf-m
