Sym Fiddle III 50 Service Manual

12. BODY COVER SYM
12-2
MAINTENANCE INFORMATION
Body covers disassemble sequence:
 Be careful not to damage various covers in disassembly or re-assembly operation.
 Never injure hooks molded on the body covers in disassembly or re-assembly operation.
 Align the buckles on the guards with slot on the covers.
 Make sure that each hook is properly installed during the assembly.
 Never compact forcefully or hammer the guard and the covers during assembly.
Left/right side cover
Top cover
Luggage box & Seat
Rear carrier
Front cover
Front Handle cover
Rear handle cover
Under cover
Rear fender
Tail light
Front fender
Front center cover
Front wheel
Floor panel
