Sym Fiddle III 50 Service Manual

SYM 6. CYLINDER HEAD/VALVE
6-1
MECHANISM DIAGRAM ....................6-1
PRECAUTIONS IN OPERATION .......6-2
TROUBLE SHOOTING.......................6-3
CAMSHAFT REMOVAL .....................6-4
CYLINDER HEAD REMOVAL ............6-6
CYLINDER HEAD DISASSEMBLY ....6-7
CYLINDER HEAD INSPECTION ......... 6-8
VALVE SEAT INSPECTION AND SERVICE 6-10
CYLINDER HEAD REASSEMBLY ....... 6-12
CYLINDER HEAD INSTALLATION...... 6-13
CAMSHAFT INSTALLATION ............... 6-13
VALVE CLEARANCE ADJUSTMENT .. 6-14
MECHANISM DIAGRAM
0.7~1.1 kgf-m
1.0~1.4 kgf-m
0.8~1.2 kgf-m
0.8~1.2 kgf-m
0.8~1.2 kgf-m
