SYM
12. BODY COVE
R
12-9
FLOOR PA
NEL
Removal
Remove the 4 screws in the battery cover.
Remove the 1 screw in the f
ront center
cover.
Remove the front center cover.
Remove the 4 bolts in the f
loor panel.
Remove the luggage box and the double
seat.
Remove the 2 bolts between th
e floor panel
and the frame.
Bolts1
×
×
×
×
2
s
crew
s
×
4
s
crew
s
×
4
s
crew
s
×
1
Front center co
ver
36
38
