Sym Fiddle III 50 Service Manual

SYM 1. GENERAL INFORMATION/TROUBLE DIAGNOSIS
1-9
SPECIFICATIONS
MAKER SANYANG MODEL XA05W-6
Overall Length 1890mm Front TELESCOPIC FORK
Overall Width 695mm
Suspen
sion
System
Rear UNIT SWING ARM
Overall Height 1135mm Front 110/70-12
DIMENSION
Wheel Base 1300 mm
Tire
Specifi
cations
Rear 120/70-12
Front 43 kg
Rear 64 kg
Front DISK (ø 190 mm)
Curb Weight
Total 107 kg
Brake
System
Rear DRUM (ø 130 mm)
Passengers/
Weight
Two men/179 kg Max. Speed Less than 45 km/hr
Front 78kg
Performa
nce
Climb Ability 22° Below
Rear 179 kg Primary Reduction C.V.T.
WEIGHT
Total Weight
Total 258kg
Secondary
Reduction
GEAR
Type 4-STROKE ENGINE Clutch Centrifugal, dry type
Installation and
arrangement
Vertical, below center,
incline 80°
Deceleration
equipment
Transmission V-belt
Fuel Used Unleaded (93/95) Speedometer 0 ~ 80 km/hr
Cycle/Cooling
4-stroke/forced air
cooled
Horn 80~112 dB/A
Bore 37.0 mm Muffler Expansion & Pulse Type
Stroke 46.0 mm
Exhaust Pipe Position
and Direction
Right side, and
Backward
Cylinder
Number/Arra
ngement
Single Cylinder Lubrication System Separated-lubrication
Displacement 49 cc CO <12.0 g/km
Compression
Ratio
12.6±0.2 : 1
Exhaust
Emission
HC <1.0 g/km
Idle Speed 2100±100 Inlet:0.05±0.02mm
25km/h 2.3 kw/6500rpm
Valve clearance
Exhaust: 0.05±0.02mm
30km/h 2.3 kw/6500rpm Fuel tank capacity 6.5L±0.3L
Max. HP
(Maximum
speed)
45km/h 2.6 kw/7500rpm
Air Filtration
Paper filter
25km/h 3.3N.m /6500 rpm Noise Emission < 80dB(A)
30km/h 3.3N.m /6500 rpm
Max. Torque
(Maximum
speed)
45km/h 3.4N.m /6500 rpm
Ignition C.D.I.
ENGINE
Starting System Electrical & Kick starter
