GTS Technical Manual
19. April 2010 Edition: V1.00/2010 5-29
Copyright © 2010, Diversey Inc.
05.0 swingo 1255 B Power - mechanics.fm
• Push bolts inwards to release the brush unit.
Make sure that you hold the brush drive unit firmly.
• Pivot the complete brush drive unit out.
Mount
On EBU models the brush unit fixation bolts are different in length.
Therefore the small bolt (06/115) is mounted on the LH and the
longer bolt (06/121) on the RH side.
• Position the brush drive unit onto the cradles.
• Position the bolts and mount the retaining ring (06/110) on
the LH and the RH side.
• Position the axle (06/114) and mount the circlip (06/112).
• Connect the brush motor wires to the power electronics.
• Connect the fresh water hoses to the brush drive unit.
• Position the brush housing on the brush drive unit.
• Position the brush housing fixation screws and tighten them.
• Close and lock the battery compartment on both sides with the
screws of the locking system.
Adjustment
• M5 (04/125) with 5 Nm
• Brush minus
• M6 (04/128) with 7 Nm
• Brush plus
