12
1
GETTING
ST
ARTED
DMS-CTC-20140127-0004 v1.0
Each Ethernet port has two LEDs:.
MoCA/Cable port (item E)
The MoCA/Cable port allows you to connect to your local coax network and to the broadband network of your services
provider.
The MoCA LED indicates the status of the MoCA interface:
Power inlet (item F)
The power inlet (Power) allows you to connect the power cord.
LED LED status Description
Top LED
(Green)
Solid on Connected to a Gigabit Ethernet device.
Blinking Connected to a Gigabit Ethernet device and sending/receiving data.
Off Not connected to a Gigabit Ethernet device.
Bottom LED
(Amber)
Solid on Connected to a 100Mbps/10Mbps device.
Blinking Connected to a 100Mbps/10Mbps device and sending/receiving data.
Off Not connected to a 100Mbps/10Mbps device.
State Description
Solid on The MoCA interface is enabled, no MoCA activity..
Blinking The MoCA interface is enabled, MoCA activity.
Off The MoCA interface is disabled or the Gateway is powered off.
