Save and Recall I
nformation
After the network connection has been established, do the following:
1. Push the front-panel Save/Recall Menu button.
2. Push the bottom-bezel File Utilities item and, from the resulting side menu, select –more–1of2. Then select Mount.
3. From the resulting side menu, set the following:
Setting Description
Drive Letter
Select from I: to Z:
Server Name or IP Address Use a USB keyboard or the on-screen interface to enter the server name or IP
address.
Path
UseaUSBke
yboard or the on-screen interface to enter the shared file path.
For example, to mount an MS Windows PC directory named “C:\Example”, enter
“C$\Example”. The dollar sign enables sharing. No colon is needed.
User Name
If necessary, use a U SB keyboard or the on-screen interface to enter the user name.
User Password
If necessary, use a US B keyboard or the on-screen interface to enter the user
passwor
d. The oscilloscope only displays “*”’s as you type the password. They are
erased from the screen after OK Accept is pushed.
NOTE. E
nsure that file sharing is enabled for the network location.
4. Push OK Accept.
NOTE. To unmount a network drive, push the front panel Save/Recall Menu button, the lower-bezel menu F ile U tilities,the
side-
menu –more–1of2, and Unmount items .
NOTE
. A ny network locations that were mounted when the oscilloscope was powered down will be automatically remounted
when the oscilloscope is powered up. Unmount any network lo cation that you do not want to automatically remount
on power up.
Printing a Hard Copy
To print an image of what appears on the oscilloscope screen, do the following procedure.
Connect a Printer to Your Oscilloscope
Connect a non-PictBridge printer to a USB port on the rear or front panel of the oscilloscope. Alternatively, connect a
PictBridge printer to the USB device port on the rear panel, or hook up a networked printer through the Ethernet port.
N
OTE. Refer to the www.tektronix.com/printer_setup Web page for a list of compatible printers.
MDO4000 Series Oscilloscopes User Manual 171
