Do not operate in wet/damp conditions.
NOTE. Be aware that condensation may occur if a unit is moved from a cold to a
warm environment.
Do not operate in an explosive atmosphere.
Keep product surfaces clean and dry. Remove the input signals before you clean
the product.
Provide proper ventilation. To ensure proper cooling, keep the sides and rear of
the instrument clear of obstructions. Slots and openings are provided for
ventilation and should never be covered or otherwise obstructed. Do not push
objects into any of the openings.
Provide a safe working environment. Always place the product in a location
convenient for viewing the display and indicators. Avoid improper or prolonged
use of button pads. Be sure your work area meets applicable ergonomic
standards.
Probes and test leads
Before connecting probes or test leads, connect the power cord from the power
connector to a properly grounded power outlet.
Keep fingers behind the finger guards on the probes.
Remove all probes, test leads and accessories that are not in use.
Use only correct Measurement Category (CAT), voltage, temperature, altitude,
and amperage rated probes, test leads, and adapters for any measurement.
Beware of high voltages. Understand the voltage ratings for the probe you are
using and do not exceed those ratings. Two ratings are important to know and
understand:
■
The maximum measurement voltage from the probe tip to the probe reference
lead
■
The maximum floating voltage from the probe reference lead to earth ground
These two voltage ratings depend on the probe and your application. Refer to the
Specifications section of the manual for more information.
WARNING. To prevent electrical shock, do not exceed the maximum measurement
or maximum floating voltage for the oscilloscope input BNC connector, probe
tip, or probe reference lead.
Connect and disconnect properly. Connect the probe output to the measurement
product before connecting the probe to the circuit under test. Connect the probe
reference lead to the circuit under test before connecting the probe input.
Disconnect the probe input and the probe reference lead from the circuit under
test before disconnecting the probe from the measurement product.
Important safety information
TBS2000B Series Oscilloscopes User Manual xv
