Appendix A: Options and Accessories
A–4
TDS 420A, TDS 430A, TDS 460A & TDS 510A User Manual
Table A–3: Optional Accessories (Cont.)
Accessory Part Number
Rackmount Kit (for field conversion) TDS 400A
TDS 510A
016-1166-00
016-1236-00
Oscilloscope Camera C9
Oscilloscope Camera Adapter 016-1154-00
Soft-Sided Carrying Case TDS 400A
TDS 510A
016-1158-01
016-0909-01
Transit Case TDS 400A
TDS 510A
016-1157-00
016-1135-01
GPIB Cable (1 meter) 012-0991-01
GPIB Cable (2 meter) 012-0991-00
TDS 400A only: Printer Pack with Seiko DPU-411 printer and
accessory pouch
TDS4F5P
Pouch (includes mounting plate) TDS 400A
TDS 510A
016-1159-00
016-1268-00
VGA Cable (Required to meet all emissions specifications) CTL3VGAMM-5
(LCOM part number)
Table A–4 lists an optional accessory amplifier and probes recommended for use
with your digitizing oscilloscope.
Table A–4: Compatible Probes
Probe Type Tektronix Model Description
Passive, high impedance voltage P6138A (TDS 400A)
P6139A (TDS 510A)
P6101B
10X, 400 MHz
10X, 500 MHz
1X, 15 MHz
Passive, SMD P6563A 20X, 500 MHz
Passive, low impedance Zo P6156 10X, 3.5 GHz, for 50 W inputs (1X, 20X, 100X optional)
Passive, high voltage P5100
P6015A
100X, 2.5 kV, DC + peak AC
1000X, 20 kV, DC + peak AC
Active, high speed voltage P6243
P6204
DC to 1 GHz FET, TekProbe powered
DC to 1 GHz FET, DC Offset capability (requires Tektronix 1103
TekProbe Power Supply for offset capability)
Active, differential voltage P6046
P5205
1X/10X, 250 V, DC to 100 MHz
50X/500X, 1300 V, DC to 100 MHz
Accessory Probes
