Appendix A: Options and Accessories
TDS 420A, TDS 430A, TDS 460A & TDS 510A User Manual
A–5
Table A–4: Compatible Probes (Cont.)
Probe Type DescriptionTektronix Model
Current AM 503S
AM 503S Opt. 03
AM 503S Opt. 05
TCP202
P6021
P6022
CT-1/CT-2
CT-4
AC/DC, Uses DC to 50 MHz A6302 Current Probe
AC/DC, Uses DC to 15 MHz A6303 Current Probe
AC/DC, Uses DC to 100 MHz A6312 Current Probe
AC/DC, DC to 50 MHz, TekProbe powered
AC, 120 Hz to 60 MHz
AC, 935 kHz to 120 MHz
Designed for permanent or semi-permanent in-circuit installation
CT-1: 25 kHz to 1 GHz, 50 W input
CT-2: 1.2 kHz to 200 MHz, 50 W input
Current Transformer for use with AM 503S and P6021. Peak pulse
1 kA, 0.5 Hz to 20 MHz with AM 503S
Logic Word Trigger P6408 16 channel, one qualifier channel, TTL compatible, +5 V power
supply required
Optical (Opto-Electric Converters) P6701A
P6703A
P6711
P6713
500 to 950 nm, DC to 850 MHz, 1 V/mW
1100 to 1700 nm, DC to 1 GHz, 1 V/mW
500 to 950 nm, DC to 250 MHz, 5 V/mW
1100 to 1700 nm, DC to 300 MHz, 5 V/mW
Table A–5 lists optional accessories that are Tektronix software products
recommended for use with your digitizing oscilloscope.
Table A–5: Accessory Software
Software Part Number
Wavewriter: AWG and waveform creation S3FT400
LabWindows for DOS
for CVI
LWDOS
LWCVI
WaveStar WSTR31
The warranty statement for this product is after the title page of this manual.
Tektronix offers the following services that you can purchase any time during the
warranty period of this product:
REP (Repair) Service Assurance provides one year of post-warranty repair
support. It is available in one year increments up to two years.
CAL (Calibrate) Service Assurance provides one year of calibration support.
It is available in one year increments up to five years.
For further information contact your Tektronix Representative.
Accessory Software
Warranty Information
Service Assurance
