Front Panel Map — Right Side (TDS 510A)
Ground
Hardcopy, page 3–47
File System, page 3–43
Autoset, page 3–113
Help, page 3–3
Status, page 3–15
Selecting Channels,
page 3–111
Horizontal Control,
page 3–55
Acquisition Modes,
page 3–5
Cursor Measurements,
page 3–117
Triggering, page 3–25
Delay Triggering, page 3–11
Edge Triggering, page 3–21
Logic Triggering, page 3–67
Pulse Triggering, page 3–91
Display Modes, page 3–17
Remote Communication, page 3–97
Vertical Control,
page 3–123
Measurement System,
page 3–73
Saving and Recalling
Setups, page 3–103
Reset the Oscilloscope,
page 2–12
Saving and Recalling
Waveforms, page 3–105
File System, page 3–43
Waveform Math,
page 3–139
Zoom,
page 3–143
Probe Compensation,
page 3–89
Cursor Measurements,
page 3–117
Removing Waveforms,
page 3–111
