Tektronix TDS 420A User Manual

At a Glance
2–4
TDS 420A, TDS 430A, TDS 460A & TDS 510A User Manual
Front Panel Map — Right Side (TDS 400A)
Cursor Measurements,
page 3–117
Acquisition Modes,
page 3–5
Display Modes, page 3–17
Remote Communication, page 3–97
Hardcopy,
page 3–47
Measurement
System,
page 3–73
Autoset,
page 3–113
Help, page 3–3
Status, page 3–15
Saving and Recalling Setups, page 3–103
Reset the Oscilloscope, page 2–12
Saving and Recalling Waveforms,
page 3–105
Selecting Channels,
page 3–111
Vertical Control,
page 3–123
Waveform Math,
page 3–139
Zoom,
page 3–143
Horizontal Control,
page 3–55
Ground
Shift, when lit, selects alternate
menus (printed in blue) and
coarse knob speed.
File System,
page 3–43
Triggering, page 3–25
Delay Triggering, page 3–11
Edge Triggering, page 3–21
Video Triggering, page 3–127
Removing Waveforms,
page 3–111
Probe Compensation,
page 3–89
