Acquiring Waveforms
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
3-29
Table 3- 1: Additional resolution bits
Sample Rate (S/s) Nd (extra samples)
Theoretical en-
hancement (bits)
Resulting effective
bits
5.00E+00 2.50E+08 13.95 13.00
1.00E+01 1.25E+08 13.45 13.00
2.50E+01 5.00E+07 12.79 13.00
5.00E+01 2.50E+07 12.29 13.00
1.00E+02 1.25E+07 11.79 13.00
2.50E+02 5.00E+06 11.13 13.00
5.00E+02 2.50E+06 10.63 13.00
1.00E+03 1.25E+06 10.13 13.00
2.50E+03 5.00E+05 9.47 13.00
5.00E+03 2.50E+05 8.97 13.00
1.00E+04 1.25E+05 8.47 13.00
2.50E+04 5.00E+04 7.80 13.00
5.00E+04 2.50E+04 7.30 13.00
1.00E+05 1.25E+04 6.80 12.80
2.50E+05 5.00E+03 6.14 12.14
5.00E+05 2.50E+03 5.64 11.64
1.00E+06 1.25E+03 5.14 11.14
2.50E+06 5.00E+02 4.48 10.48
5.00E+06 2.50E+02 3.98 9.98
1.00E+07 1.25E+02 3.48 9.48
2.50E+07 5.00E+01 2.82 8.82
5.00E+07 2.50E+01 2.32 8.32
1.00E+08 1.25E+01 1.82 7.82
2.50E+08 5.00E+00 1.16 7.16
5.00E+08 2.50E+00 0.66 6.66
1.25E+09 1.00E+00 0.00 6.00
