Tenda AC7 User Manual

102
11.6 Device management
11.6.1 Reboot the router
If any parameter fails to take effect or the router does not work properly, you can try rebooting the
router.
Rebooting the router will disconnect all connections to the router. Reboot the router during leisure
time.
To reboot the router, log in to the web UI of the router and choose Administration > Device
Management. Click Reboot to reboot the router.
Wait for a moment until the ongoing process finishes. The router reboots successfully.
11.6.2 Reset the router
If you are uncertain about why the internet is inaccessible through the router or you forget the
login password of the router, you can reset the router.
⚫
Resetting the router is not recommended unless you cannot find a solution for the current
problem anyway. You need to reconfigure the router after it is reset.
⚫
Ensure that the power supply of the router is normal when the router is reset. Otherwise the
router could be damaged.
⚫
The default login IP address is 192.168.0.1 after resetting, and no password is required.
Reset the router using the reset button
If the router only has one LED indicator, hold down the reset button for about 8 seconds and
release it when the LED indicator blinks fast. The router is reset.
If the router only has multiple LED indicators, hold down the reset button for about 8 seconds and

Tenda AC7 Specifications

General

VPN support	IPsec pass through, PPTP pass through, L2TP pass through, PPTP server, PPTP client, L2TP client
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB port	No
Ethernet LAN (RJ-45) ports	4
Transmit power	30 dBmW
Antennas quantity	5
Antenna gain level (max)	6 dBi
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN
Output current	1 A
Output voltage	9 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Package type	Box
Package weight	860 g
Number of products included	1 pc(s)
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Firewall security	Forbid UDP flood attack, Forbid TCP flood attack, Forbid flood attack, Forbid WAN PING from internet
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK, WPS
Certification	CE, FCC, RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	141.5 mm
Width	220 mm
Height	49 mm
Weight	360 g
