Tenda AC7 User Manual

73
9.5.2 Enable internet users to access LAN resources using a
domain name
Scenario: You have set up an FTP server within your LAN.
Goal: Open the FTP server to internet users and enable family members who are not at home to
access the resources of the FTP server from the internet with a domain name.
Solution: You can configure the DDNS and port forwarding functions to reach the goal.
Assume that the information of the FTP server includes:
− IP address: 192.168.0.136
− MAC address of the host: D4:61:DA:1B:CD:89
− Service port: 21
The information of the registered DDNS service:
− Service provider: oray.com
− User name: JohnDoe
− Password: JohnDoe123456
− Domain name: o2849z7222.zicp.vip
Please ensure that router obtains an IP address from the public network. This function may not work
on a host with an IP address of a private network or an intranet IP address assigned by ISPs that start
with 100. Common IPv4 addresses are classified into class A, class B and class C. Private IP addresses of
class A range from 10.0.0.0 to 10.255.255.255; Private IP addresses of class B range from 172.16.0.0-
172.31.255.255; Private IP addresses of class C range from 192.168.0.0-192.168.255.255.
FTP server
− IP: 192.168.0.136
− MAC: D4:61:DA:1B:CD:89
− Port number: 21
The information of the registered DDNS
service:
− Service provider: oray.com
− User name: JohnDoe
− Password: JohnDoe123456
− Domain name: o2849z7222.zicp.vip
Smart phone
Computer
Access using a
domain name

Tenda AC7 Specifications

General

VPN support	IPsec pass through, PPTP pass through, L2TP pass through, PPTP server, PPTP client, L2TP client
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB port	No
Ethernet LAN (RJ-45) ports	4
Transmit power	30 dBmW
Antennas quantity	5
Antenna gain level (max)	6 dBi
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN
Output current	1 A
Output voltage	9 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Package type	Box
Package weight	860 g
Number of products included	1 pc(s)
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Firewall security	Forbid UDP flood attack, Forbid TCP flood attack, Forbid flood attack, Forbid WAN PING from internet
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK, WPS
Certification	CE, FCC, RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	141.5 mm
Width	220 mm
Height	49 mm
Weight	360 g
