Tenda AC7 User Manual

72
9.5 DDNS
9.5.1 Overview
DDNS normally interworks with port forwarding, DMZ host and remote management, so that the
internet users can be free from the influence of dynamic WAN IP address and access the internal
server or the router’s web UI with a fixed domain name.
To access the configuration page, log in to the web UI of the router, and choose Advanced > DDNS.
This function is disabled by default. When it is enabled, the page is shown as below.
Parameter description
Parameter
Description
DDNS
It specifies whether to enable the DDNS function.
Service Provider
It specifies a DDNS service provider, including oray.com, 88ip.cn and dyn.com.
DDNS User Name
It specifies the user name and password registered on a DDNS service provider's website
for logging in to the DDNS service.
DDNS Password
DDNS Host Name
It specifies the domain name you applied on the website of your service provider.
It is only required when dyn.com is chosen as the service provider.
Connection
Status
It specifies the current connection status of the DDNS service.

Tenda AC7 Specifications

General

VPN support	IPsec pass through, PPTP pass through, L2TP pass through, PPTP server, PPTP client, L2TP client
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB port	No
Ethernet LAN (RJ-45) ports	4
Transmit power	30 dBmW
Antennas quantity	5
Antenna gain level (max)	6 dBi
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN
Output current	1 A
Output voltage	9 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Package type	Box
Package weight	860 g
Number of products included	1 pc(s)
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Firewall security	Forbid UDP flood attack, Forbid TCP flood attack, Forbid flood attack, Forbid WAN PING from internet
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK, WPS
Certification	CE, FCC, RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	141.5 mm
Width	220 mm
Height	49 mm
Weight	360 g
