Tenda AC7 User Manual

43
5.4 Wireless parameters
In this section, you can change network mode, wireless channel, and wireless bandwidth of 2.4
GHz and 5 GHz WiFi networks.
To access the configuration page, log in to the web UI of the router, and choose Wireless Settings >
Wireless Parameters.
In order not to influence the wireless performance, it is recommended to maintain the default settings
on this page without professional instructions.
Parameter description
Parameter
Description
Network
Mode
It specifies various protocols adopted for wireless transmission.
2.4 GHz WiFi network supports 11b, 11g, 11b/g mixed and 11b/g/n mixed modes.
⚫
11b: It indicates that devices compliant with IEEE 802.11b protocol can connect to the 2.4 GHz
WiFi network of the router, enjoying a maximum transmission rate of 11 Mbps.
⚫
11g: It indicates that devices compliant with IEEE 802.11g protocol can connect to the 2.4 GHz
WiFi network of the router, enjoying a maximum transmission rate of 54 Mbps.
⚫
11b/g: It indicates that devices compliant with IEEE 802.11b or IEEE 802.11g protocol can
connect to the 2.4 GHz WiFi network of the router, enjoying a maximum transmission rate of
54 Mbps.
⚫
11b/g/n: It indicates that all devices compliant with IEEE 802.11b or IEEE 802.11g protocol, or
work at 2.4 GHz with IEEE 802.11n protocol can connect to the 5 GHz WiFi network of the
router, therefore enjoying a maximum transmission rate of 300 Mbps.
5 GHz WiFi network supports 11ac, 11a/n/ac mixed modes.
⚫
11ac: It indicates that devices complaint with IEEE 802.11ac protocol can connect to the 5 GHz
WiFi network of the router, enjoying a maximum transmission rate of 867 Mbps.
⚫
11a/n/ac: It indicates that all devices compliant with IEEE 802.11a or IEEE 802.11ac protocol, or
work at 5 GHz with IEEE 802.11n protocol can connect to the 5 GHz WiFi network of the router,
enjoying a maximum transmission rate of 867 Mbps.

Tenda AC7 Specifications

General

VPN support	IPsec pass through, PPTP pass through, L2TP pass through, PPTP server, PPTP client, L2TP client
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB port	No
Ethernet LAN (RJ-45) ports	4
Transmit power	30 dBmW
Antennas quantity	5
Antenna gain level (max)	6 dBi
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN
Output current	1 A
Output voltage	9 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Package type	Box
Package weight	860 g
Number of products included	1 pc(s)
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Firewall security	Forbid UDP flood attack, Forbid TCP flood attack, Forbid flood attack, Forbid WAN PING from internet
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK, WPS
Certification	CE, FCC, RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	141.5 mm
Width	220 mm
Height	49 mm
Weight	360 g
