REMOVING A HALOGEN LAMP HOLDER
Refer to Figure 13 for the following steps.
1. Turn off the electrical power to the oven.
2. Remove the oven racks.
3. Remove the oven rack support for the
halogen lamp holder you are removing.
CAUTION: Make sure that the halogen bulb
is cool before you remove it in the next step.
4. Pull the lamp cover out of the halogen
lamp holder and remove the bulb.
WARNING
Turn off the electrical power circuit to the
oven at the main junction box before ser-
vicing this unit.
When you work on the oven, be careful
when handling the sheet metal parts. There
are sharp edges present and you can cut
yourself if you are not careful.
CAUTION
5. Pry the lamp holder out of the oven liner
and cut the wires approximately 2" from
the lamp holder body. CAUTION: Be
careful not to chip or scratch the oven
liner when you pry the lamp holder out
of the cutout.
6. Cut the plug off the new lamp holder.
7. Connect the cut wires to the new lamp
holder with two red inline splices. After
you connect the wires, pull on them to
make sure that the inline splices are se-
cure.
8. Gently pull the lamp holder wires up into
the plenum area until you can see the red
wire splices in the plenum area.
9. Reassemble the oven.
TECH
TIP!!
Make sure that the two red inline splices are
in the top plenum area and not in the oven
heat zone.
