REMOVING AN OVEN DOOR
Refer to Figure 30 for the following steps.
1. Open the door to its fully open position.
2. Raise the hinge latch over the hook on
each of the hinges.
Position Up To
Remove Door
Position Down
To Close Door
3. To remove the door:
a) Grasp the door by the sides toward the
back and raise the front of the door sev-
eral inches (there will be some resis-
tance in the spring mechanism because
the hinge is locked).
b) When the door is high enough, lift it
until the hinges clear the indents, and
pull it out of the slots in the front frame.
Hinge Latch
Figure 30
Page 44
