“C” Oven Relay Boards
RELAY BOARD MATRIX
REPLAY FUNCTION
K0 Upper Oven Latch Motor
K1 Lower Oven Latch Motor
K2 None
K3 None
K4 Upper Oven Cooling Motor
K5 Lower Oven Cooling Motor
K6 Upper Oven Halogen TX
K7 Lower Oven Halogen TX
K8 Upper Oven Bake Element
K9 Upper Oven Broil Element
K10 Upper Oven Convection Element
K11 Upper Oven Convection Motor
K12 Lower Oven Bake Element
K13 Lower Oven Broil Element
K14 Lower Oven Convection Element
K15 Lower Oven Convection Motor
