“C” OVEN Sequence of Events
Roast Mode
K4 Relay Closes
Cooling Motor Runs
Air Switch Closes
Completed Circuit
Signals Board
P14 Activates
DLB Relay Coil
DLB Relay
Contacts Close
120 Volts from
L1 Flow to
Bake/Broil Element
NO
K8 Relay Closes
K9 Relay Closes
120 Volts from
L2 Flow to
Bake Element
120 Volts from
L2 Flow to
Broil Element
Relays K
8 and K
9
will alternately open and close
➜
➜
➜
➜
➜
➜
PRESS START
➜
➜
➜
➜
➜
➜
➜
➜
Incomplete Circuit
Flashes F34 or F64
and shuts unit off
