tothenegative(–)terminalofthebatteryand
securethemwiththeboltsandnuts(Figure6).
Slidetherubberbootoverthepositiveterminal
topreventapossibleshortfromoccurring.
WARNING
Incorrectbatterycableroutingcoulddamage
thetractorandcables,causingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Alwaysdisconnectthenegative(black)
batterycablebeforedisconnectingthe
positive(red)cable.
•Alwaysconnectthepositive(red)battery
cablebeforeconnectingthenegative
(black)cable.
g005098
Figure6
1.Negative(-)
2.Positive(+)
3
InstallingtheRollBar
Partsneededforthisprocedure:
1Rollbar
4
Bolt(5/8x4-1/2inch)
4
Locknut(5/8inch)
Procedure
1.Positiontherollbarsothetopofthetubeis
curvedtowardthefrontofthemachine(Figure
7).
g019975
Figure7
1.Rollbar
3.Locknut(5/8inch)
2.Bolt(5/8x4-1/2inch)
2.Lowertherollbarontotheframe,aligningitwith
themountingholes(Figure7).
3.Secureeachsideoftherollbartotheframe
with2bolts(5/8x4-1/2inches)andlocknutsas
showninFigure7.
4.Torquethefastenersto183to223N∙m(135to
165ft-lb).
4
ReducingtheTirePressure
NoPartsRequired
Procedure
Thetiresareover-inatedatthefactoryforshipping
purposes.Reducethepressuretotheproperlevels
beforestartingthemachine.RefertoCheckingthe
TirePressure(page39).
12
