Lubrication

GreasingtheMachine

ServiceInterval:Every50hours(Also,applygrease

aftereverywashing.)

Themachinehasgreasettingsthatmustbe

lubricatedregularlywithNo.2general-purpose,

lithium-basegrease.Ifthemachineisoperatedunder

normalconditions,lubricateallbearingsandbushings

afterevery50hoursofoperation.Lubricatettings

immediatelyaftereverywashing,regardlessofthe

intervallisted.

Thefollowingmachinebearingsandbushingsmust

belubricated:

•Rearwheelhub(1)(Figure28)

g008439

Figure28

•Castorbearing(1)(Figure28)

•Steeringcylinder(2)(Figure28)

•Liftarms(3)(Figure29)

g008440

Figure29

•Tractionpedalpivot(1)(Figure30)

g008441

Figure30

•Carrierframepivot(3)(Figure31)

g016483

Figure31

1.Wipethegreasettingcleansoforeignmatter

cannotbeforcedintothebearingorbushing.

2.Pumpgreaseintothebearingorbushing.

3.Wipeupexcessgrease.

4.Applygreasetothereelmotorsplineshaftand

ontotheliftarmwhenthecuttingunitisremoved

forservice.

5.ApplyafewdropsofSAE30engineoilorspray

lubricant(WD40)dailytoallpivotpointsafter

cleaning.

Note:RefertotheCuttingUnitOperator’sManualfor

cuttingunitlubricationrequirements.
